Floor Repair System

Description

DE-450 Floor Repair Compound is a Polymer modified epoxy based compound having good Mechanical Properties.

Applications

Designed for use on concrete as well as metal parts. Typical uses are repairs of damaged floors, repairs of rotary or stationary equipment foundation repairs, resurfacing of the industrial floors. Since it has abrasion resistant it can be used for heavy duty applications on industrial floors and can be used in metal parts or equipments in tandem with suitable system.

Advantages

Easy to use and apply, can bond to metal as well as concrete surfaces, abrasion resistantance, excellent bond strength, minimum downtime with ease of application, suitable for vertical applications, chemical resistant.

Typical Properties
Property Value As per Specification
Color Natural Visual
Adhesive Tensile Shear 125 kg/cm2
Compressive strength (K/cm2) 550 kg/cm2ASTM D 695
Coverage 10kgs/ one sq mtr@4mm thickTheoretical
Cure Time 6-8hours depending on temperature
Cured Hardness (Shore D) 85ASTM D 2240
Flexural Strength (Kg/cm2) 150ASTM D 790
Adhesion Strength (Kg/cm2) 30ASTM D 4541
Mix Ratio by Weight 13.4:6.6:80
Pot Life @ 30è C 60 min.
Recoat Time 8-10 hrs
Solids by Volume 100
Temperature Resistance Up to 120.C
Working Time 45 min. 30° C
Surface Preparation
  • The surface must be cleaned thoroughly. If contaminated with oil or grease, use solvents to clean the surface properly.
  • For damp or moisture surfaces, forced drying should be resorted. surface properly.
  • Use mechanical equipments like scarifier or floor polishing machine before application for achieving required anchorage.
  • Excessive scarifying may result in reduced coverage.
Mixing Instructions
  • It is strongly recommended that full units be mixed.
  • Add part 'B' into part 'A'. mix it thoroughly and add part 'C'; in stipulated ratio.
  • Mix thoroughly with screwdriver or similar tool (continuously scrape material away from sides and bottom of container) uniform.
  • Large batch mixing: Use a propeller-type Jiffy Mixer on an electric drill. Mix until homogenous.
Chemical Resistance
Trichloroethane Very good
Ammonia Very good
Cutting Oil Very good
Gasoline (Unleaded) Very good
Hydrochloric Acid 10% Very good
Kerosene Very good
Methyl Ethyl Ketone Poor
Methylene Chloride Poor
Phosphoric Acid 10% Very good
Potassium Hydroxide 20% Very good
Sodium Chloride Brine Very good
Sodium Hydroxide 10% Very good
Sulfuric Acid 10% Very good
Sulfuric Acid, 50% Poor
Tri sodium Phosphate Very good
Xylene Fair
Storage

Store at Room Temperature (Preferably below 32° C) and away from Sunlight

Shelf life

Although the product undergoes no chemical changes even during very long storage, some rise in viscosity and some settling may occur after storage for more than one year and it would be advisable to conduct a small quantity trial when the material is to be used after one year.

Packing : 1KIT = 57.5 KG
